Fuse link CH10x38 aM 32A/400V 002621015 Obsolete
This product is obsolete and has been replaced with CH10x38 aM 32A/400V.
Compare products
Specifications
- ETI Code:
- 002621015
- Description:
- *CH10x38 aM 32A/400V
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- CH
- Size:
- 10x38
- Rated current (A):
- 32
- Rated AC voltage (V):
- 400
- Characteristics:
- aM
- Breaking capacity AC (kA):
- 100
- Application:
- For relays, contactors and motors protection in case of short-circuit
- Power dissipation (W):
- 1,2
- Standards:
- IEC 60269-1, IEC 60269-2
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895906568
- Net weight of the product
- 7.6 g
- Customs tariff
- 85361050
- logis_net_width
- 10 mm
- logis_net_height
- 38 mm
- logis_net_depth
- 10 mm
Basic packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895169567
- Basic packaging weight
- 0.08 kg
Transport packaging
- Transport packaging quantity
- 500
- EAN code for a transport packaging
- 3838895169574
- Transport packaging weight
- 4.1 kg
- Pallet quantity
- 84000
ETIM Clasification
- Classification
- EC002704
- Class name
- Cylindrical fuse
- Size
- 10x38 mm
- Utilization category
- AM
- Nominal current
- 32A
- Breaking capacity
- 100kA
Characteristic
Images & Diagrams
Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
*CH10x38 aM 32A/400V
