Surge arrester MOD. SM T2 DC 500/20 S 002440730
Specifications
- ETI Code:
- 002440730
- Description:
- MOD. SM T2 DC 500/20 S
- Class name:
- Surge arrester
- Function:
- SPD Module
- Type:
- T2
- For use with:
- ETITEC SM T2 DC
Documents
Logistic Data
Product
- EAN code for a single product
- Net weight of the product
- 0.076 kg
- Customs tariff
- 85363090
Level 1 Packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895966173
- Basic packaging weight
- 0.084 kg
Level 2 Packaging
- Transport packaging quantity
- 24
- EAN code for a transport packaging
- 3838895966180
- Transport packaging weight
- 2.207 kg
- Pallet quantity
- 5760
ETIM Clasification
- Classification
- EC000941
- Class name
- Surge protection device for power supply systems
- Degree of protection (IP), front side
- IP20
- System configuration DC
- Yes
- System configuration IT
- No
- System configuration TN
- No
- System configuration TN-C
- No
- System configuration TN-S
- No
- System configuration TT
- No
- System configuration other
- No
- Nominal discharge surge current (8/20)
- 20
- Nominal voltage DC
- 450
- Short-circuit breaking capacity (Isccr)
- 30
- Max. continuous voltage AC
- 500
- Max. discharge surge current (8/20)
- 65
- Max. continuous voltage DC
- 1000
- Mounting method
- On basic element
- Voltage protection level
- 2,5
- Integrated backup fuse
- No
- Signalling at the device
- Optical
- Category type 2
- Yes
- Degree of protection (IP)
- IP20
MOD. SM T2 DC 500/20 S
