Fuse link CH10x38SU gPV 5A/1000V DC 002625124
Specifications
- ETI Code:
- 002625124
- Description:
- CH10x38SU gPV 5A/1000V DC
- Class name:
- Fuse link
- Type:
- CH-SU
- Size:
- CH10
- Rated current (A):
- 5
- Rated DC voltage (V):
- 1000
- Characteristics:
- gPV
- L/R (ms):
- 2
- Breaking capacity DC (kA):
- 30
- Application:
- For protection of photovoltaic modules
- Dimensions:
- 10x38
- Power dissipation (0,7x In) (W):
- 0,63
- Power dissipation (W):
- 1,49
- Operating joule integral (A2s):
- 21
- Prearcing joule integral (A2s):
- 8
- Standards:
- IEC 60269-6
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400056290
- Net weight of the product
- 10.2 g
- Customs tariff
- 85361010
- logis_net_width
- 10 mm
- logis_net_height
- 60 mm
- logis_net_depth
- 11 mm
Level 1 Packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895627647
- Basic packaging weight
- 0.106 kg
Level 2 Packaging
- Transport packaging quantity
- 380
- EAN code for a transport packaging
- 3838895627654
- Transport packaging weight
- 4.12 kg
- Pallet quantity
- 63840
ETIM Clasification
- Classification
- EC002704
- Class name
- Cylindrical fuse
- Construction size
- CH10
- Rated current
- 5
- Rated voltage DC
- 1000
- Application
- For protection of photovoltaic modules
- Size
- 10x38 mm
- Rated voltage
- Other
- Utilization category
- Other
- Nominal current
- 5A
