Lamp L1 1p 2W BLUE 002431104 Obsolete
This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.
Specifications
- ETI Code:
- 002431104
- Description:
- *L1 1p 2W BLUE
- Class name:
- Lamp
- Catalogue Group:
- Push-button
- Catalogue subgroup:
- Signal light L1
- Function:
- Signal light L1
- Rated current (A):
- 2
- Rated DC voltage (V):
- 24
- Number of poles:
- 1
- Max input cross-section (mm²):
- 1x6 mm² / 2x2,5 mm², max. 1 Nm
- Rated Frequency (Hz):
- 50/60 Hz
- Standards:
- IEC/EN 60947-1, IEC/EN 60947-3
- Utilization category:
- AC-22A
Documents
Logistic Data
Product
- EAN code for a single product
- 38388951296406
- Net weight of the product
- 0.073 kg
- Customs tariff
- 85365080
Basic packaging
- Basic packaging quantity
- 12
- EAN code for a basic packaging
- 3838895298274
- Basic packaging weight
- 0.87 kg
Transport packaging
- Transport packaging quantity
- 108
- EAN code for a transport packaging
- 3838895298304
- Transport packaging weight
- 8.2 kg
- Pallet quantity
- 7020
Intermediate packaging
- Weight
- 0.076
*L1 1p 2W BLUE
