Fuse link NH2 SWF 160A/500V 004714226
Specifications
- ETI Code:
- 004714226
- Description:
- NH2 SWF 160A/500V
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- NH
- Size:
- NH2
- Rated current (A):
- 160
- Rated AC voltage (V):
- 500
- Characteristics:
- gR
- Breaking capacity AC (kA):
- 100
- Application:
- Safe work fuses
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 40
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895761457
- Net weight of the product
- 580 g
- Customs tariff
- 85361090
- logis_net_width
- 54 mm
- logis_net_height
- 150 mm
- logis_net_depth
- 73 mm
Basic packaging
- Basic packaging quantity
- 3
- EAN code for a basic packaging
- 3838895630364
- Basic packaging weight
- 2.08 kg
Transport packaging
- Transport packaging quantity
- 15
- EAN code for a transport packaging
- 3838895630371
- Transport packaging weight
- 16.99 kg
- Pallet quantity
- 780
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- NH2
- Rated current
- 160
- Rated voltage
- 500
- Voltage type
- AC
- Rated switching capacity
- 100
- Utilization category
- gR (general purpose semiconductor protection)
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
