Fuse link TRB 125A/80V 004341025
Specifications
- ETI Code:
- 004341025
- Description:
- TRB 125A/80V
- Class name:
- Fuse link
- efuse:
- 1
- Rated current (A):
- 125
- Type:
- TRB
- Rated DC voltage (V):
- 80
- Application:
- Forklift battery protection
- Standards:
- DIN 43560/1
Documents
Logistic Data
Product
- Net weight of the product
- 0.02 kg
- Customs tariff
- 85361090
- logis_net_width
- 22 mm
- logis_net_height
- 82 mm
- logis_net_depth
- 11 mm
Transport packaging
- Transport packaging quantity
- 10
- EAN code for a transport packaging
- 3838895456186
- Transport packaging weight
- 0.2 kg
- Pallet quantity
- 23140
ETIM Clasification
- Classification
- EC002298
- Class name
- Blade fuse
- Application
- Forklift battery protection
- Rated voltage DC
- 80
- Rated current
- 125
- Nominal current
- 125A
Characteristic
