Fuse link DII UQ gR 2A/500V 004322001
Specifications
- ETI Code:
- 004322001
- Description:
- DII UQ gR 2A/500V
- Class name:
- Fuse link
- efuse:
- 1
- Product group:
- Semiconductor Protection
- Type:
- D
- Size:
- DII
- Rated current (A):
- 2
- Rated AC voltage (V):
- 500
- Rated DC voltage (V):
- 315
- Characteristics:
- gR
- Breaking capacity AC (kA):
- 50
- Breaking capacity DC (kA):
- 8
- Application:
- For protection of semiconductor devices
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 2,1
- Operating joule integral (A2s):
- 5,8
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400052025
- Net weight of the product
- 24 g
- Customs tariff
- 85361010
- logis_net_width
- 22 mm
- logis_net_height
- 50 mm
- logis_net_depth
- 22 mm
Basic packaging
- Basic packaging quantity
- 5
- EAN code for a basic packaging
- 3838895012177
- Basic packaging weight
- 0.13 kg
Transport packaging
- Transport packaging quantity
- 500
- EAN code for a transport packaging
- 3838895166085
- Transport packaging weight
- 13.5 kg
- Pallet quantity
- 26000
ETIM Clasification
- Classification
- EC000099
- Class name
- D-system fuse link
- Rated voltage DC
- 315
- Breaking capacity
- 50
- Application
- For protection of semiconductor devices
- Type of fuse status indicator
- Top fuse status indicator
- Max. rated operation voltage Ue AC
- 500
- Construction size
- DII
- Rated current
- 2A
- Rated voltage
- 500V
- Colour code
- Pink
- Utilization category
- Other
- Release characteristic
- Super fast (FF)
Characteristic
