Fuse link NHS3/110 UQ01 aR 1000A/1000V 004305132

Specifications

ETI Code:
004305132
Description:
NHS3/110 UQ01 aR 1000A/1000V
Class name:
Fuse link
efuse:
1
Product group:
Semiconductor Protection
Type:
NH-S
Size:
NH3
Rated current (A):
1000
Rated AC voltage (V):
1000
Characteristics:
aR
Breaking capacity AC (kA):
200
Application:
For protection of semiconductor devices
Indicator:
Top fuse status indicator
Power dissipation (W):
157
Operating joule integral (A2s):
2.000.000
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838895360698
Net weight of the product
1250  g
Customs tariff
85361090
logis_net_width
73  mm
logis_net_height
139  mm
logis_net_depth
73  mm

Basic packaging

Basic packaging quantity
3
EAN code for a basic packaging
3838895348511
Basic packaging weight
2.65  kg

Transport packaging

Transport packaging quantity
15
EAN code for a transport packaging
3838895560272
Transport packaging weight
13.5  kg
Pallet quantity
15
Classification
EC000055
Class name
Low Voltage HRC fuse
Construction size
NH3
Rated current
1000
Rated voltage
1000
Voltage type
AC
Rated switching capacity
200
Type of fuse status indicator
Top fuse status indicator
Insulated metal gripping lugs (IMGL)
No
ETIM Classification – Version 7.0
