Fuse link NHS2/110 UQ01 aR 400A/1000V 004304123
Specifications
- ETI Code:
- 004304123
- Description:
- NHS2/110 UQ01 aR 400A/1000V
- Class name:
- Fuse link
- efuse:
- 1
- Product group:
- Semiconductor Protection
- Type:
- NH-S
- Size:
- NH2
- Rated current (A):
- 400
- Rated AC voltage (V):
- 1000
- Characteristics:
- aR
- Breaking capacity AC (kA):
- 200
- Application:
- For protection of semiconductor devices
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 80
- Operating joule integral (A2s):
- 170.000
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- Net weight of the product
- 880 g
- Customs tariff
- 85361090
- logis_net_width
- 60 mm
- logis_net_height
- 150 mm
- logis_net_depth
- 60 mm
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895348436
- Basic packaging weight
- 0.75 kg
Transport packaging
- Transport packaging quantity
- 16
- EAN code for a transport packaging
- 3838895560104
- Transport packaging weight
- 12.35 kg
- Pallet quantity
- 832
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- NH2
- Rated current
- 400
- Rated voltage
- 1000
- Voltage type
- AC
- Rated switching capacity
- 200
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
Characteristic
