Fuse link NHS00/80 UQ01 aR 80A/1000V 004301113
Specifications
- ETI Code:
- 004301113
- Description:
- NHS00/80 UQ01 aR 80A/1000V
- Class name:
- Fuse link
- efuse:
- 1
- Product group:
- Semiconductor Protection
- Type:
- NH-S
- Size:
- NH00
- Rated current (A):
- 80
- Rated AC voltage (V):
- 1000
- Characteristics:
- aR
- Breaking capacity AC (kA):
- 200
- Application:
- For protection of semiconductor devices
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 27,4
- Operating joule integral (A2s):
- 2.400
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895360582
- Net weight of the product
- 0.25 kg
- Customs tariff
- 85361090
- logis_net_width
- 29 mm
- logis_net_height
- 104 mm
- logis_net_depth
- 67 mm
Basic packaging
- Basic packaging quantity
- 3
- EAN code for a basic packaging
- 3838895346470
- Basic packaging weight
- 0.85 kg
Transport packaging
- Transport packaging quantity
- 54
- EAN code for a transport packaging
- 3838895559740
- Transport packaging weight
- 15.65 kg
- Pallet quantity
- 2808
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- NH00
- Rated current
- 80
- Rated voltage
- 1000
- Voltage type
- AC
- Rated switching capacity
- 200
- Utilization category
- aR (accompanied semiconductor protection)
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
