Fuse link VVT-D3 24kV/2A AG 004252033
Specifications
- ETI Code:
- 004252033
- Description:
- VVT-D3 24kV/2A AG
- Class name:
- Fuse link
- efuse:
- 1
- Rated minimum breaking current (A):
- 355
- Cold resistance (mΩ):
- 12.9
- Rated current (A):
- 100
- Type:
- NEW VVT-D 80N Thermo striker
- Size:
- 442
- Rated AC voltage (V):
- 24000
- Indicator:
- Temperature limiter, 80N striker force
- Breaking capacity AC (kA):
- 63
- Application:
- transformer protection, motor protection, capacitor bank protection, installation in ring main unit
- Power dissipation (W):
- 220
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895926665
- Net weight of the product
- 2.4 kg
- Customs tariff
- 85351000
- logis_net_width
- 56 mm
- logis_net_height
- 442 mm
- logis_net_depth
- 56 mm
Transport packaging
- Transport packaging quantity
- 3
- EAN code for a transport packaging
- 3838895926672
- Transport packaging weight
- 7.67 kg
- Pallet quantity
- 108
Intermediate packaging
- Weight
- 2.4
