Fuse link NH1 gG 200A/400V MET 004113839
Specifications
- ETI Code:
- 004113839
- Description:
- NH1 gG 200A/400V MET
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- NH
- Size:
- NH1
- Rated current (A):
- 200
- Characteristics:
- gG
- Application:
- As metering fuse with strip fuse switch disconnector and fuse switch disconnector
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 12
- Standards:
- IEC EN 60269-1
Documents
Logistic Data
Product
- Net weight of the product
- 350 g
- Customs tariff
- 85361090
- logis_net_width
- 46 mm
- logis_net_height
- 136 mm
- logis_net_depth
- 62 mm
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895618331
- Basic packaging weight
- 0.5 kg
Transport packaging
- Transport packaging quantity
- 26
- EAN code for a transport packaging
- 3838895618348
- Transport packaging weight
- 13.5 kg
- Pallet quantity
- 1352
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- NH1
- Rated current
- 200
- Rated voltage
- 400
- Voltage type
- AC
- Rated switching capacity
- 50
- Utilization category
- gL/gG (cable protection/equipment protection)
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
