Fuse link NH2XL gG 315A/1200V 004113747
Specifications
- ETI Code:
- 004113747
- Description:
- NH2XL gG 315A/1200V
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- NH
- Size:
- 2XL
- Rated current (A):
- 315
- Rated AC voltage (V):
- 1200
- Characteristics:
- gG
- Breaking capacity AC (kA):
- 50
- Application:
- For cable protection
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 35
- Standards:
- IEC 60269
Documents
Logistic Data
Product
- Net weight of the product
- 1050 g
- Customs tariff
- 85351000
- logis_net_width
- 55 mm
- logis_net_height
- 209 mm
- logis_net_depth
- 71 mm
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895602149
- Basic packaging weight
- 1.05 kg
Transport packaging
- Transport packaging quantity
- 12
- EAN code for a transport packaging
- 3838895631620
- Transport packaging weight
- 13.67 kg
- Pallet quantity
- 624
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- Other
- Rated current
- 315
- Rated voltage
- 1200
- Voltage type
- AC
- Rated switching capacity
- 50
- Utilization category
- gL/gG (cable protection/equipment protection)
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
