Fuse link NH1 100A/440V DC 004110227
Specifications
- ETI Code:
- 004110227
- Description:
- NH1 100A/440V DC
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- NH
- Size:
- NH1
- Rated current (A):
- 100
- Rated DC voltage (V):
- 440
- Characteristics:
- gR
- L/R (ms):
- 20
- Breaking capacity DC (kA):
- 50
- Application:
- Fuse-link for DC application.
- Indicator:
- Top fuse status indicator
- Standards:
- IEC 60269-2
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895760993
- Net weight of the product
- 290 g
- Customs tariff
- 85361090
- logis_net_width
- 29 mm
- logis_net_height
- 135 mm
- logis_net_depth
- 64 mm
Basic packaging
- Basic packaging quantity
- 3
- EAN code for a basic packaging
- 3838895450474
- Basic packaging weight
- 0.732 kg
Transport packaging
- Transport packaging quantity
- 45
- EAN code for a transport packaging
- 3838895450481
- Transport packaging weight
- 11 kg
- Pallet quantity
- 2340
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- NH1
- Rated current
- 100
- Rated voltage
- 440
- Voltage type
- DC
- Rated switching capacity
- 50
- Utilization category
- gR (general purpose semiconductor protection)
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
Characteristic
