Fuse link CH14x51 aM 4A/690V 002631003 Obsolete
This product is obsolete and has been replaced with CH14x51 aM 4A/690V.
Compare products
Specifications
- ETI Code:
- 002631003
- Description:
- *CH14x51 aM 4A/690V
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- CH
- Size:
- 14x51
- Rated current (A):
- 4
- Rated AC voltage (V):
- 690
- Characteristics:
- aM
- Breaking capacity AC (kA):
- 80
- Application:
- For relays, contactors and motors protection in case of short-circuit
- Power dissipation (W):
- 0,6
- Standards:
- IEC 60269-1, IEC 60269-2
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400031082
- Net weight of the product
- 18.75 g
- Customs tariff
- 85361010
- logis_net_width
- 14 mm
- logis_net_height
- 51 mm
- logis_net_depth
- 14 mm
Basic packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895169604
- Basic packaging weight
- 0.186 kg
Transport packaging
- Transport packaging quantity
- 500
- EAN code for a transport packaging
- 3838895169611
- Transport packaging weight
- 9.8 kg
- Pallet quantity
- 85000
ETIM Clasification
- Classification
- EC002704
- Class name
- Cylindrical fuse
- Size
- 14x51 mm
- Utilization category
- AM
- Nominal current
- 4A
- Breaking capacity
- 80kA
Characteristic
Images & Diagrams
Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
*CH14x51 aM 4A/690V
