Fuse link CH10x85SU gR 16A/1200V DC 002625236

Specifications

ETI Code:
002625236
Description:
CH10x85SU gR 16A/1200V DC
Class name:
Fuse link
efuse:
1
Designed for:
Protection of PV installations
Product subgroup:
PV
Product group:
Special purpose fuses
L/R (ms):
2
Type:
CH SU
Size:
10x85
Rated current (A):
16
Rated DC voltage (V):
1200
Characteristics:
gR
Breaking capacity DC (kA):
30
Application:
For protection of semiconductor devices
Power dissipation (0,7x In) (W):
1,57
Power dissipation (W):
3,65
Prearcing joule integral (A2s):
141
Operating joule integral (A2s):
177
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838400052742
Net weight of the product
18.1  g
Customs tariff
85351000
logis_net_width
10  mm
logis_net_height
107  mm
logis_net_depth
11  mm

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895611943
Basic packaging weight
0.195  kg

Transport packaging

Transport packaging quantity
160
EAN code for a transport packaging
3838895611950
Transport packaging weight
3.2  kg
Pallet quantity
27200
Classification
EC002704
Class name
Cylindrical fuse
Rated current
16
Construction size
CH10
Application
For protection of semiconductor devices
Rated voltage DC
1200
Size
Other
Rated voltage
Other
Utilization category
Other
Nominal current
16A
ETIM Classification – Version 7.0
