Fuse link CH10x85SU gR 12A/1200V DC 002625235
Specifications
- ETI Code:
- 002625235
- Description:
- CH10x85SU gR 12A/1200V DC
- Class name:
- Fuse link
- efuse:
- 1
- Designed for:
- Protection of PV installations
- Product subgroup:
- PV
- Product group:
- Special purpose fuses
- L/R (ms):
- 2
- Type:
- CH SU
- Size:
- 10x85
- Rated current (A):
- 12
- Rated DC voltage (V):
- 1200
- Characteristics:
- gR
- Breaking capacity DC (kA):
- 30
- Application:
- For protection of semiconductor devices
- Power dissipation (0,7x In) (W):
- 1,31
- Power dissipation (W):
- 3,47
- Prearcing joule integral (A2s):
- 41
- Operating joule integral (A2s):
- 63
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400052735
- Net weight of the product
- 18.1 g
- Customs tariff
- 85351000
- logis_net_width
- 10 mm
- logis_net_height
- 107 mm
- logis_net_depth
- 11 mm
Basic packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895611912
- Basic packaging weight
- 0.195 kg
Transport packaging
- Transport packaging quantity
- 160
- EAN code for a transport packaging
- 3838895611929
- Transport packaging weight
- 3.2 kg
- Pallet quantity
- 27200
ETIM Clasification
- Classification
- EC002704
- Class name
- Cylindrical fuse
- Construction size
- CH10
- Rated voltage DC
- 1200
- Application
- For protection of semiconductor devices
- Rated current
- 12
- Size
- Other
- Rated voltage
- Other
- Utilization category
- Other
- Nominal current
- 12A
Characteristic
