Fuse link CH10x38 aR 10A/600V 002625007
Specifications
- ETI Code:
- 002625007
- Description:
- CH10x38 aR 10A/600V
- Class name:
- Fuse link
- efuse:
- 1
- Product group:
- Semiconductor Protection
- Type:
- CH
- Size:
- 10x38
- Rated current (A):
- 10
- Rated AC voltage (V):
- 600
- Characteristics:
- aR
- Breaking capacity AC (kA):
- 200
- Breaking capacity DC (kA):
- 50
- Application:
- For protection of semiconductor devices
- Power dissipation (W):
- 2,5
- Operating joule integral (A2s):
- 70
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895362470
- Net weight of the product
- 0.026 kg
- Customs tariff
- 85361010
- logis_net_width
- 10 mm
- logis_net_height
- 38 mm
- logis_net_depth
- 10 mm
Transport packaging
- Transport packaging quantity
- 10
- EAN code for a transport packaging
- 3838895356172
- Transport packaging weight
- 0.1 kg
- Pallet quantity
- 75000
ETIM Clasification
- Classification
- EC002704
- Class name
- Cylindrical fuse
- Construction size
- CH10
- Rated current
- 10
- Max. rated operation voltage Ue AC
- 600
- Application
- For protection of semiconductor devices
- Size
- 10x38 mm
- Utilization category
- Other
- Nominal current
- 10A
- Breaking capacity
- 200kA
Characteristic
