Fuse link CH10x38 gG 2A/500V 002620001 Obsolete
This product is obsolete and has been replaced with CH10x38 gG 2A/500V.
Compare products
Specifications
- ETI Code:
- 002620001
- Description:
- *CH10x38 gG 2A/500V
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- CH
- Size:
- 10x38
- Rated current (A):
- 2
- Rated AC voltage (V):
- 500
- Characteristics:
- gG
- Breaking capacity AC (kA):
- 100
- Application:
- For cable protection
- Power dissipation (W):
- 1
- Standards:
- IEC 60269-1, IEC 60269-2
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895581512
- Net weight of the product
- 7.6 g
- Customs tariff
- 85361010
- logis_net_width
- 10 mm
- logis_net_height
- 38 mm
- logis_net_depth
- 10 mm
Basic packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895137665
- Basic packaging weight
- 0.08 kg
Transport packaging
- Transport packaging quantity
- 500
- EAN code for a transport packaging
- 3838895164951
- Transport packaging weight
- 4.1 kg
- Pallet quantity
- 84000
ETIM Clasification
- Classification
- EC002704
- Class name
- Cylindrical fuse
- Size
- 10x38 mm
- Utilization category
- Other
- Nominal current
- 2A
- Breaking capacity
- 100kA
Characteristic
