Shunt trip release DA ETIMAT P10/R 110-250V AC/DC 001908414
Specifications
- ETI Code:
- 001908414
- Description:
- DA ETIMAT P10/R 110-250V AC/DC
- Class name:
- Shunt trip release
- Function:
- Shunt trip
- Rated Frequency (Hz):
- 50/60
- Terminals (mm²):
- 1-25
- For use with:
- ETIMAT P10R
Documents
Logistic Data
Product
- EAN code for a single product
- Net weight of the product
- 125 g
- Customs tariff
- 85362010
Level 1 Packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895972839
- Basic packaging weight
- 0.15 kg
Level 2 Packaging
- Transport packaging quantity
- 54
- EAN code for a transport packaging
- 3838895972846
- Transport packaging weight
- 8.14 kg
- Pallet quantity
- 2808
ETIM Clasification
- Classification
- EC001023
- Class name
- Shunt release (for power circuit breaker)
- Connectable conductor cross section multi-wired
- 1-25
- Type of drive
- 50/60
- Rated control supply voltage AC 50 Hz
- 110...250V
- Rated control supply voltage DC
- 110...250V
- Voltage type for actuating
- AC/DC
- Type of electric connection
- Screw connection
