Changeover switch LBS 800 4P CO 004661565
Specifications
- ETI Code:
- 004661565
- Description:
- LBS 800 4P CO
- Class name:
- Changeover switch
- No. Of poles:
- 4
- Thermal current Ith (A):
- 800
- Rated operational current Ie AC-21 A/B at 415V (A):
- 800
- Rated insulation voltage (V):
- 1000
- Max. rated operational voltage (V AC):
- 690
- Mounting:
- Panel mounted
Documents
Logistic Data
Product
- EAN code for a single product
- Net weight of the product
- 36.6 kg
- Customs tariff
- 85365080
- logis_net_width
- 466 mm
- logis_net_height
- 321 mm
- logis_net_depth
- 375 mm
Level 1 Packaging
- EAN code for a basic packaging
Level 2 Packaging
- Transport packaging quantity
- 1
- EAN code for a transport packaging
- 3838895719786
- Transport packaging weight
- 36.6 kg
- Pallet quantity
- 4
ETIM Clasification
- Classification
- EC000216
- Class name
- Switch disconnector
- Version as main switch
- Yes
- Version as maintenance-/service switch
- Yes
- Version as safety switch
- Yes
- Max. rated operation voltage Ue AC
- 415V
- Rated permanent current Iu
- 800A
- Rated operation power at AC-23, 400 V
- 450kW
- Number of poles
- 4
- Suitable for floor mounting
- Yes
- Type of control element
- Toggle
